General
|
| Capacity (VA) |
3500 |
| Capacity (Watts) |
2450 |
Input
|
| Generator Compatibility |
Yes |
| Nominal Input Voltage (Vac) |
220, 230, 240 |
| Input Voltage Range (Vac) |
140 ~ 300 Vac |
| Input Frequency (Hz) |
50 ± 5, 60 ± 5 |
| Input Frequency Detection |
Auto-sensing |
| Input Connector Type |
Hardwire Terminal Block |
Output
|
| Output Waveform |
Pure Sine Wave |
| Output Voltage(s) (Vac) |
220 ± 5%, 230 ± 5%, 240 ± 5% |
| Output Frequency (Hz) |
50 ± 1%, 60 ± 1% |
| Automatic Voltage Regulation (AVR) |
Single Boost, Single Buck |
| Overload Protection (On Utility) |
Circuit Breaker |
| Overload Protection (On Battery) |
Internal Current Limiting |
| Manual Switch |
Normal, Bypass with AVR, Bypass, Off |
| Outlet(s) - Total |
3 |
| Outlet Type |
Hardwire Terminal Block x 1, Schuko x 2 |
| Typical Transfer Time (ms) |
10 |
Surge Protection & Filtering
|
| Lightning / Surge Protection |
Yes |
Management & Communications
|
| LCD Panel |
Yes |
| LED Indicators |
Power On, Wiring Fault |
| Audible Alarms |
Battery Mode, Low Battery, Overload, Overcharge, Overheat |
| Power Management Software |
PowerPanel® Business (Recommended) |
| SNMP / HTTP Remote Monitoring |
Yes - with optional RMCARD205 |
Physical
|
| Wheels |
Yes |
Physical Size
|
| Dimensions (WxHxD) (mm.) |
260 x 440 x 330 |
| Weight (kg.) |
36.53 |
Environmental
|
| Operating Temperature (°C) |
0 ~ 40 |
| Operating Relative Humidity (Non-condensing) (%) |
0 ~ 95 |
Certifications
|
| Certifications* |
CE, EAC, SONCAP |
| RoHS |
Yes |
External Battery (Optional)
|
| Battery Type |
Sealed Lead-acid |
| Battery Voltage (Vdc) |
24 |
